Commodity;IHPCU-600 Edge IoT Intelligent Measurement and Control Device
Application :Used for the energy consumption and power environment monitoring
Monitoring in the distribution room of industrial enterprises,large public buildings,
Schools,hospitals etc
PRODUCTS OVERIVEW
Carries out online monitoring edge computing,data analysis and linkage control on the environment,security and electrical equipment status of the intelligent distribution room to ensure the safe operation of the distribution room.Prevent accidents caused by environmental changes,unauthorized activities,equipment status changes,etc.,and realize remote automatic operation,maintenance and scheduling of the distribution room.SF6 content in that environment of the power distribution room,O2content,temperature and humidity,intrusion,access control and other states are monitored in real time,calculated and diagnosed online,and the fan,lighting,dehumidification,water pump,image acquisition and other equipment are controlled and linked according to the preset starting mode.Real-time monitoring of equipment busbar and transformer temperature monitoring ,partial discharge monitoring in the cabinet.
KEY FEATURE
|
Parameter |
Data |
|
|
RS485 |
Way quantity |
7ways communication interface with ESD 15KV protection function 1way RS232 interface |
|
|
Working mode |
Main station working mode |
|
|
Baud rate |
1200~115200bps |
|
|
Protocol |
Modbus-RTU、DL/T645-2007、CJ/T188-2004 etc |
|
|
Number of slaves |
≥64sets/sub way,max 500sets in total series |
|
|
Data length |
≥200Byte/slave |
|
AI input |
Way quantity |
2 ways |
|
|
Input range |
DC 0~10V or 4~20mA |
|
DI input |
Way quantity |
8 ways |
|
|
Type |
Dry contact point built-in 12V excitation |
|
DO output |
Way quantity |
8 ways |
|
|
Type |
5A/250V(pure resistive load),one public contact point/4ways |
|
Ethernet |
Way quantity |
2 ways |
|
|
Working mode |
Uplink customer terminal mode |
|
|
Max speed |
100M |
|
|
Protocol |
DHCP、IP、ICMP、UDP、DHCP、DNS、TCP、HTTP、TFTP、XML、MQTT |
|
|
Connection quantity |
Max 10 parallel connections |
|
4G-CAT 1 |
Way quantity |
1 way |
|
|
Working mode |
Uplink customer terminal mode |
|
|
Protocol |
DHCP、IP、ICMP、UDP、DHCP、DNS、TCP、HTTP、TFTP、XML、MQTT |
|
|
WIFI hot point |
Accept 4 network cameras |
|
Satellite positioning |
Type |
GRS + Beidou |
|
Acquisition cycle |
Order from main station,real-time collection,time interval 1-60 minutes free setting |
|
|
Data storage |
16G storage capacity,at least one year |
|
|
External interface |
1 way expanding USD external interface |
|
|
Data transmission |
AES encrypted data transmission supportable, Break point resume/failure point location supportable |
|
|
Gateway |
WEB page |
|
|
Upgrading |
Remote upgrading supportable |
|
|
Power supply |
AC/DC 85V～265V Power consumption：main body≤10VA |
|
|
Safety |
Power frequency Withstand voltage |
AC 2kV/1min |
|
|
Insulation resistance |
>100MΩ； |
|
Working temperature |
-25℃～+65℃ |
|
|
Relative humidity |
≤95% no condensation |
|
|
Elevation |
≤2500m |
|
IHPCU-600 Edge IoT Intelligent Measurement and Control Device
