PRODUCT

ENTERPRISE BRIEF INTRODUCTION

HK750 Precision Distribution Cabinet Intelligent Monitoring Unit

PRODUCT OVERVIEW

The unit is an intelligent system for the energy end of the computer room,comprehensive collection of all energy data.Provide high-precision measurement data fo the terminal energy monitoring system of the head cabinet,and reflect the power quality data in real time through the display unit.It is digitally communicated and uploaded to the background environmental control system.In order to achieve real-time monitoring of the entire power distribution system and effective management of operation quality.Help users optimize network data centers,strengthen energy consumption management,and improve server rack operation efficiency,to achieve all-round green to provide reliable guarantee for the IDC computer room.

KEY FEATURE

High precision data provided
Direct current type also available
Multiple circuits provided(total up to 4groups)
More requirment customizable

技术参数：

WORKING POWER SUPPLY	85～265V AC OR 120～300V DC
MTTF	≥50000 hours
Working life	10 years
Rated voltage	AC/ 220V(phase)，range 10%～120% rated value；accuracy 0.5%
Rated current input	AC5A，range 1%～120% rated value；accuracy 0.5%
Rate current ouput	AC100A，range 1%～120% rated value；accuracy 0.5%
Rated frequency	50Hz，range 45～60Hz，±0.01Hz
Accuracy (input)	Active power energy 0.5S，current/voltage 0.5
Accuracty(output)	Active power energy 1.0，current/voltage 0.5
Communication interface	RS485， bps 4800、9600、19200、38400(optional)
Switch value	Passive signal output/input，AC 220V， 70%～120% rated value
Relay capacity	AC 250V/5A or DC 30V/5A
